DRIVEPOWERFULLY
COMPATIBLE
EFFICIENTLY
Support: 12~24S 200A
THUNDER ESC is designed for high power drone
MULTI-TUBE CONNECTION, LESS HEAT
Multiple MOS transistors are driven in parallel and the internal resistance is doubled down
STACK TECHNOLOGY, COOLING FASTER
The power module is stacked with the aluminum alloy shell for higher heat dissipation efficiency
MULTIPLE PROTECTIONS DOUBLE SECURITY
With multiple protections, effectively prolonging the service life of the ESC
Power-on self-test
Overvoltage protection
Overcurrent protection
Over temperature protection
Throttle signal loss protection
ANTI-SIGNAL INTERFERENCE
Using shielded wires, throttle control and serial data feedback signals are fully isolated, effectively isolating internal and external interference
PREMIUM ELECTRONICS RIGOROUS TEST
All electronics were selected from rigorous tests
ESC have passed high-voltage and full-power load tests
WATERPROOF PROTECTION
The anti-corrosion shell and a fully enclosed design with a protection IP54, Isolate effectively rainwater, dust, and resist corrosion from pesticides and other liquids, Provide comprehensive protection for the safe operation of ESCs
CUSTOMIZED SERVICES
ELECTRIC PROPELLERfunction
UART-TTLdata feedback protocol
