Technical Drawing
Specification
| Motor Size | Φ87.3*29.55mm | Lead Cable | 90mm |
| Stator | Anti-rust treatment; 180℃ high temperature-resisting coatings | Copper Wire | 220℃ high temperature resistance |
| Configuration | 36N42P | Coil Insulation Test | 1000V/5s |
| Shaft Diameter | IN：12mm | Rotor Dynamic Balance Standard | ≤15Mg |
| Bearing | Imported 6901ZZ | IP | IP56 |
| Magnet Level | 180℃ high temperature resistance | Packing Size | 130*111*50.6mm |
| KV | 100 | Rated Voltage(Lipo) | 12S(4.2V/pc) / 48-52V |
| Idle Current(24V) | 1.0A | Internal Resistance | 134-141mΩ |
| Peak Current(180s) | 31A | Weight (Incl. Cable) | 287g |
| Max. Power(180s) | 1450W | Package Weight | 454g |
Test Data
| Type | Propeller | Throttle | Voltage (V) | Thrust (g) | Torque (N*m) | Current (A) | RPM | Power (W) | Efficiency (g/W) | Operating Temperature (℃) |
| U8II Pro KV100 | T-MOTO G27*8.8 | 40% | 48 | 2038 | 0.61 | 3.47 | 1935 | 165 | 12.33 | 90℃ |
| 45% | 48 | 2542 | 0.76 | 4.68 | 2155 | 223 | 11.42 | |||
| 50% | 48 | 3000 | 0.90 | 5.95 | 2330 | 283 | 10.60 | |||
| 55% | 48 | 3458 | 1.03 | 7.24 | 2489 | 344 | 10.05 | |||
| 60% | 47 | 3956 | 1.17 | 8.72 | 2651 | 414 | 9.55 | |||
| 65% | 47 | 4491 | 1.33 | 10.43 | 2808 | 495 | 9.08 | |||
| 70% | 47 | 4888 | 1.44 | 11.87 | 2926 | 561 | 8.72 | |||
| 75% | 47 | 5442 | 1.61 | 13.90 | 3078 | 656 | 8.29 | |||
| 80% | 47 | 5958 | 1.77 | 16.05 | 3220 | 756 | 7.88 | |||
| 90% | 47 | 7052 | 2.09 | 20.75 | 3488 | 973 | 7.25 | |||
| 100% | 47 | 8442 | 2.51 | 27.64 | 3794 | 1289 | 6.55 | |||
T-MOTOR G28*9.2 | 40% | 47 | 2260 | 0.72 | 3.92 | 1900 | 186 | 12.15 | 104℃ | |
| 45% | 47 | 2843 | 0.90 | 5.43 | 2120 | 257 | 11.05 | |||
| 50% | 47 | 3307 | 1.04 | 6.71 | 2277 | 317 | 10.43 | |||
| 55% | 47 | 3787 | 1.18 | 8.19 | 2434 | 387 | 9.79 | |||
| 60% | 47 | 4323 | 1.33 | 9.87 | 2586 | 466 | 9.28 | |||
| 65% | 47 | 4851 | 1.51 | 11.71 | 2729 | 551 | 8.81 | |||
| 70% | 47 | 5396 | 1.67 | 13.79 | 2863 | 647 | 8.35 | |||
| 75% | 47 | 5905 | 1.83 | 15.72 | 2991 | 736 | 8.02 | |||
| 80% | 47 | 6479 | 1.99 | 17.96 | 3120 | 840 | 7.71 | |||
| 90% | 47 | 7663 | 2.35 | 23.31 | 3367 | 1088 | 7.04 | |||
| 100% | 47 | 9122 | 2.81 | 31.11 | 3673 | 1450 | 6.29 | |||
| Note: Motor temperature is motor surface temperature at 100% throttle running 10mins. (Date above based on benchtest are for reference only, comparion with that of other motor types is not recommended.) | ||||||||||
Packing List
Before using this product, please check if all the items listed above are included in the packaging. If there are any missing items, please contact our online customer service or leave message to " onlinesales@tmotor.com " in time.
