X-A16-24S

The preferred solution for 220~240kg coaxial multirotor drones

X-A16-24SMOTOR

24S FOC 260AESC

EFZ6324/EZ6324PROPELLER

X-A16-24S RECOMMENDATIONS

Load capacity (weight)

140~160kgAgricultureQuadcopter Drone

Take-off weight

220~240kgQuadcopter

Load capacity (weight)

250~280kgAgricultureHexacopter Drone

Take-off weight

330~360kgHexacopter

Technical Drawing


Specification

Model No.	X-A16-24S KV35	Tube Size	80mm
Setup	A16-24S (Motor)+24S FOC 260A (ESC)+EFZ6324/EZ6324 (Propeller)	Wire Material, Wire Gauge, Color	Power Wires: 8#AWG Red & Black Signal Wires: 5+1 Shielded
Recommended Battery	24~28S (LiPo)	Wire Length	2400±5mm
Rated Thrust	55~60kg	Weight	13180±2%g (Incl. Wires+Propeller)
Efficiency At Rated Thrust	7.2g/W (55kg)	IP	IPX5
Max. Thrust	132kg	Recommended Ambient Temperature	-20~55℃

Motor Specs
Stator Size	155*23.5mm	KV	35

ESC Specs
Throttle Range	1100~1940us (Fixed)	Max. Voltage	126V
Protocol	DRONE CAN、UAV CAN、 CUBE CAN	Peak Current (For A Short Time)	260A (OpenEnvironment AndTemperature≤60℃)
Control Method	PWM/CAN	BEC	NO

Prop Specs

Model No.

EFZ6324

(Folding Carbon Fiber)

EZ6324 (One-piece Carbon Fiber Propeller) Optional

Length

EFZ63: 1130g/EZ63: 640g

Weight

EFZ63: 1130g/EZ63: 640g

Test Data

Type	Voltage (V)	Throttle	Current (A)	Thrust (gf)	Torque (N·m)	RPM	Motor Efficiency (%)	Overall Efficiency (gf/W)	Operating Temperature (℃)
X-A16-24S KV35 + 24S FOC 260A + EFZ6324/EZ6324	92	30%	9.24	13308	10.75	739	97.73	15.63	89 (Ambient Temperature: 25)
		35%	17.61	20090	15.98	900	95.80	12.38
		40%	27.77	27609	21.93	1053	94.44	10.79
		45%	42.66	36238	28.63	1201	91.57	9.22
		50%	57.61	45620	36.03	1341	90.26	8.59
		55%	82.74	55633	44.06	1477	89.75	7.30
		60%	104.08	65819	52.33	1604	89.64	6.86
		65%	133.97	76559	61.03	1728	89.42	6.20
		70%	165.64	87641	69.99	1843	88.40	5.74
		75%	202.78	98972	79.20	1954	86.73	5.30
		80%	239.98	109819	88.21	2058	85.93	4.96
		85%	272.53	118547	95.32	2134	84.81	4.72
		90%	306.62	126717	101.98	2200	83.12	4.48
		95%	332.53	131956	106.75	2244	81.86	4.31
		100%	342.59	132510	106.85	2245	79.56	4.20
Note: Temperature in the chart is the bell temperature after running @80% throttle for 2min. (Data above based on benchtest at T-MOTOR lab are for reference only.)

Motor Analysis Chart

Packing List
